Transmissions
V & Wedge Belts
Megadyne Belts
Megadyne V & Wedge Belts
B Section
Quick Code: BB-550221
B138 Megadyne Oleostatic Gold Belt
Buy Now
Qty:
Product Specification
Brand
Megadyne
External Length
3575mm
Internal Length
3505mm
Pitch Length
3548mm
Top Width x Depth
17mm x 11mm
Reference
390700950152
Quick Order Code
BB-550221
Product Description
Oleostatic Gold show up to 30% more power transmission capacity than standard Oleostatic belts. This allows more compact drive and cost reduction.All the compound are halogen-free and RoHS compliant.
Main Components:
Fabric
- A reinforced, double fabric cover is plied around the belt to protect it against contamination and moisture. Its increased flexibility allows the belt to bend more easily around the smallest pulleys with far less strain on the fabric, while assuring a smoother running drive.
Top Cushion
- SBR compound + fibers
Tensile Cord
- The tensile section is made up of a multiple number of high-strength, low elongation polyester cords, completely embedded in the adhesion layers, to enhance resistance to tension and flex-fatigue. Each cord is individually and specially coated to secure a long-lasting bond with the surrounding rubber and to grant a longer operational lifetime. In addition the belt requires significantly less re tensioning and take-up due to its cords consistent length stability. Longer belt life means less frequent replacement, less downtime and lower maintenance costs
Bottom Cushion
- SBR compound + fibers
Body Compound
- Polycloroprene (CR) based
