Quick Code: BB-293132
TEC IE3 37kW 3ph 6 Pole, B5 Flange Mount, 250 Frame, Cast Iron Electric Motor
Buy Now
Qty:
Product Specification
Frame Size
250
Pole
6
Power
37kW
Shaft Size
65mm
Speed
975rpm
Reference
37.063TECCB5-IE3 250 Frame
Brand
Tec
Quick Order Code
BB-293132
Product Description
TEC IE3 Electric Motor 37kW 3ph 6 Pole B5 Flanged Mounted, 250 Frame, Cast Iron These cast iron three phase IE3 electric motors are energy saving and are highly efficient, having higher starting torques with lower starting current. They are versatile, easy to modify and are able to adapt to various applications.
It has full use of the magnetization properties of cold rolled silicone steel in which the stator laminations are magnetized evenly. This is to reduce the temperature rise inside the winding. In addition, the motor has dimensional interchangeability which means it is either the same or shorter than many motors currently offered.
They are most commonly used in the following applications: conveyors, air compressors and fans, paper mills, pumps, mining equipment, agriculture and so on.
