Quick Code: BB-38274
TEC IE2 Electric Motor 0.55kW 3ph 4 Pole B5 Flange Mounted, 80 Frame
Buy Now
Qty:
Product Specification
Bolt Hole Centre (M)
165mm
Flange Dia (P)
200mm
Frame
80M
Overall Motor Length (L)
290mm
Pole
4
Power - KW
0.55
Shaft Dia (D)
19mm
Shaft Length (E)
40mm
Speed - RPM
1400
Reference
0.5543TECAB5 / 0.5543TEEB5 (80 Frame)
Brand
Tec
Quick Order Code
BB-38274
Product Description
TEC IE2 Electric Motor 0.55kW 3ph 4 Pole B5 Flange Mounted, 80 Frame
These aluminium frame 3 phase electric motors, complete with B5 flange mounting, suit a wide range of industrial and commercial applications. They adhere to the latest European mechanical and electrical standards and are rugged and reliable. They are of a high quality, suit wet and dusty environments, have a lightweight aluminium construction and are efficiency IE2 rated.
These electric motors can be used in applications such as air conditioners, packing equipment, fans, hydraulics, agricultural and so on. If you use these motors you can improve efficiency and save space as these motors are more compact and run smoother than their single phase counterparts, in addition to providing nearly twice the power. As they have water and dust tight cooling fans, the operating conditions can be preserved inside the unit in most working environments. Key points:
